NS200YA Speaker
The iVSEC NS200YA is a compact IP audio terminal designed for indoor paging and communication environments. With a wall-mounted form factor and clean design it is well suited to offices classrooms retail spaces and commercial facilities requiring reliable voice broadcasting and intercom functionality.
Delivering 15W output and up to 105dB sound pressure the iVSEC NS200YA provides clear wide-area audio coverage. It supports HD codecs such along with MP3 and WAV playback for high-quality music and announcements while a built-in microphone enables two-way intercom communication.
The iVSEC NS200YA supports SIP protocol multicast paging and integration with third-party systems including surveillance and access control. With features like scheduled broadcasts emergency paging and multiple management options via web or software platforms it offers a flexible and scalable solution for modern IP-based audio systems.
| Colour |
White |
| Mouning |
Wall |
| SIP Accounts |
8 |
| Multicast Partitions |
20 |
| Customised Audio Support |
Yes |
| Auto Answer |
Yes |
| HTTP/Webhook Support |
Yes |
| DTMF Support |
Yes |
| Web GUI |
Yes |
| Storage Capacity Mb |
500 |
| ONVIF |
Yes |
| Protocols |
DHCP FTP/TFTP HTTP/HTTPS IPv6 L2TP OpenVPN PPPoE RTP/RTCP/SRTP SIP2.0 SNTP STUN TR-069 |
| Encoding |
G.711A/U G.722 G723 G726-32K G.729A/B iLBC Opus |
| Language |
English |
| Auto-Provisioning |
Yes |
| Outdoor Use |
No |
| Accessories |
n/a |
| Frequency Response |
100Hz-20KHz |
| Speaker Sensitivity |
100Hz-20KHz |
| Impedance |
8Ω |
| Max SPL |
105dB |
| Speaker Power Max |
8W PoE 15W PoE 15W 24V DC/2A |
| Additional Speaker Support |
1 x 8Ω 15W speaker when powered via 24V DC |
| Microphone |
Yes |
| Microphone Sensitivity |
-38± 3dB |
| Self Testing Feature |
Yes |
| Ethernet |
Yes 10/100 Mbps |
| Power Over Ethernet |
Yes |
| Power Supply |
24V DC/2A PoE PoE |
| Power Consumption |
48W max |
| Connectors |
2 Pin DC input 1 x 8Ω Speaker Output 1 x RJ45 port |
| Wi-Fi |
No |
| Bluetooth |
No |
| Operating Environment |
-20&8451; – 55&8451; 10-95 RH |
| Storage Environment |
-30&8451; – 60&8451; |
| In The Box |
1 x SIP Speaker 1 x Quick Guide |
| Warranty |
2 Years Parts |
| Product Dimensions H x W x L mm |
276 x 185 x 125 |
| Packaging Dimensions H x W x L mm |
350 x 190 x 182 |
| Weight Net kg |
13.74 |
| Weight Gross kg |
15.56 |
More Information
Manufacturer
Warranty
Part Number
IVNS200YA
