Apc Smart-ups 750va/500w Line

APC Smart-UPS, Line Interactive, 750VA, Tower, 230V, 6x IEC C13 outlets, SmartConnect Port+SmartSlot, AVR, LCD

This APC Smart-UPS is designed for IT professionals or network administrators to maintain business uptime and continuity. The 750VA line interactive tower UPS provides pure sine wave power to support critical electronics during power disruptions. It offers cloud-based remote power monitoring, UPS firmware upgrades, remote diagnostics and proactive email notifications with recommended actions.The UPS can connect to EcoStruxure IT or third-party centralized management platforms. It provides surge protection against lightning strikes, power sags, brownouts and surges.
Main Input Voltage 230 V
Other Input Voltage 220 V, 240 V
Main Output Voltage 230 V
Other Output Voltage 220 V, 240 V
Rated power in W 500 W
Rated power in VA 750 VA
Input Connection Type IEC 320 C14
Output connection type 6 IEC 320 C13, 2 IEC Jumpers
Cable length 1.83 m
Number of cables 1
Battery type Lead-acid battery
Provided equipment USB cable
(power cable not included)
Input voltage limits 151…302 V adjustable, 160…280 V
Network frequency 50/60 Hz +/- 3 Hz auto-sensing
Harmonic distortion Less than 5 %
Maximum configurable power in VA 750 VA
Maximum configurable power in W 500 W
Transfer time 6 ms typical : 10 ms maximum
Output frequency 50/60 Hz +/- 3 Hz sync to mains
Acoustic level 40 dBA
Heat dissipation 90 Btu/h
Operating altitude 0…10000 ft
Ambient air temperature for operation 0…40 °C
Ambient air temperature for storage -15…45 °C
Storage altitude 0.00…15240.00 m
Relative humidity 0…95 %
Storage Relative Humidity 0…95 %

Mounting mode- Not rack mountable
Replacement Battery -RBC48
Compatible PDU- AP6015A, AP7820B, AP7850B, AP7920B, AP7950B
Compatible Service bypass panels- SBP1500RMI
Compatible Sensors- AP9335T, AP9335TH
Compatible NMC -AP9613, AP9620, AP9640, AP9641, AP9643, AP9810

More Information

Manufacturer

APC

Warranty

36

Product Information

Datasheet

Optional Accessories

UPAPC-RBC48, UPAPC-AP9613, UPAP-AP4421, UPAPC-CFWEPLUS1YRSU1, UPAPC-CFWEPLUS3YRSU1, UPAPC-AP9640, UPAPC-AP9641
